DC-DC Converters
High-reliability DC-DC solutions for EV, solar, and industrial power electronics.
Use Cases
Traction systems, auxiliary power, and energy storage integration.
Highlights
- High efficiency, low ripple
- Protections and thermal design
- Wide input/output ranges
DC‑DC Converters — Technical Specifications
| Parameter | 0.5 kW Model | 1 kW Model | 2 kW Model | 6 kW Model |
|---|---|---|---|---|
| Operating temperature | –40 °C to 85 °C | –40 °C to 85 °C | –40 °C to 85 °C | –40 °C to 85 °C |
| Nominal output power | 500 W | 1 kW | 2 kW | 6 kW (6.5 kW peak) |
| Input voltage range | 400–750 V DC | 400–750 V DC | 400–750 V DC | 400–750 V DC |
| Nominal output voltage | 12 / 24 / 48 V DC options | 12 / 24 / 48 V DC options | 12 / 24 / 48 V DC options | 12 / 24 / 48 V DC options |
| Nominal output current | 12 V: 40 A; 24 V: 20 A; 48 V: 10 A | 12 V: 80 A; 24 V: 40 A; 48 V: 20 A | 12 V: 160 A; 24 V: 80 A; 48 V: 40 A | 12 V: 500 A; 24 V: 250 A; 48 V: 125 A |
| Auxiliary power | 9–32 V DC | 9–32 V DC | 9–32 V DC | 9–32 V DC |
| Efficiency | ≥95 % (typical) | ≥95 % (typical) | ≥95 % (typical) | ≥96 % (typical) |
| Output ripple | ≤500 mV | ≤500 mV | ≤500 mV | ≤400 mV |
| Voltage accuracy | ±1 % | ±1 % | ±1 % | ±1 % |
| Wake‑up | KL15 (hard-wire) | KL15 (hard-wire) | KL15 (hard-wire) | KL15 (hard-wire) |
| Communication | CAN-BUS | CAN-BUS | CAN-BUS | CAN-BUS + RS485 |
| Static current | ≤2 mA | ≤2 mA | ≤2 mA | ≤3 mA |
| EMC compliance | CISPR 25 | CISPR 25 | CISPR 25 | CISPR 25 Class 3 |
| Protections | Input OVP/UVP, Output OVP/UVP, Over‑temperature, Input reverse, Output short‑circuit, Over‑current | Input OVP/UVP, Output OVP/UVP, Over‑temperature, Input reverse, Output short‑circuit, Over‑current | Input OVP/UVP, Output OVP/UVP, Over‑temperature, Input reverse, Output short‑circuit, Over‑current | Input OVP/UVP, Output OVP/UVP, Over‑temperature, Input reverse, Output short‑circuit, Over‑current + surge suppression |
